30–500TPD Full Lepidolite Plant Crushing Milling Flotation Line
Release time：
2026-07-10
Source：
GoFine
Lepidolite lithium mica ore remains a cost-effective and sustainable lithium resource for global new energy manufacturing, widely mined in Southeast Asia, Africa and South America. Unlike hard and high-grade spodumene, natural lepidolite features fine disseminated grains, high clay slime content and complex symbiosis with quartz, feldspar and other gangue minerals, requiring matched crushing, milling and flotation systems to achieve qualified concentrate. A 30–500TPD full lepidolite plant integrating complete crushing, milling and flotation units is a modular, scalable turnkey solution tailored for small and medium-sized lithium mica mines.
This full-process lepidolite production line covers flexible capacity from 30TPD micro pilot scale to 500TPD formal commercial production, realizing one-stop ore processing from raw ore size reduction to final lithium concentrate output. Different from scattered single equipment configuration, the integrated crushing milling flotation line perfectly matches particle size grading, grinding fineness and flotation parameters, effectively solving common lepidolite beneficiation problems such as uneven grinding, serious fine particle loss and low lithium recovery.
Complete Process Logic of Lepidolite Crushing Milling Flotation Line
Lepidolite beneficiation success depends on coordinated three core links: precise crushing control, graded fine milling and targeted acidic flotation. Every process step of the 30–500TPD full lepidolite plant is optimized for lithium mica’s physical and chemical characteristics, avoiding over-crushing, over-grinding or insufficient mineral dissociation that restricts flotation efficiency.
Crushing and milling serve as the pre-beneficiation foundation to liberate monomer lithium mica particles from gangue minerals, while flotation acts as the core separation unit to remove impurities and upgrade concentrate. The whole production line adopts closed-circuit circulation design to reduce ore waste and reagent consumption, ensuring stable and efficient operation of small and medium-scale lepidolite mining projects.
Standard Full Flow of 30–500TPD Lepidolite Processing Line
The integrated crushing, milling and flotation line adopts a mature low-loss closed-loop workflow, realizing continuous and automatic production of lepidolite concentrate. The compact and reasonable process layout adapts to limited site conditions of remote small-scale mines.
Raw ore uniform feeding → primary jaw crushing → secondary fine crushing → vibrating screening classification → closed-circuit ball mill milling → hydrocyclone grading & deep desliming → pulp acidic conditioning → automatic reagent dosing → roughing flotation → scavenging flotation → multi-stage cleaning flotation → concentrate thickening → filter press dehydration → finished lepidolite concentrate stacking → tailings dry discharge
Compared with ordinary lithium processing lines, this full lepidolite plant adds multi-stage desliming and fine particle recovery modules after milling. It thoroughly removes clay slime generated during crushing and grinding, prevents reagent failure caused by slime adsorption, and greatly improves the utilization rate of fine-grained lithium mica ore.
Capacity Configuration & Operational Performance Parameters
The 30–500TPD full lepidolite plant supports flexible capacity customization and modular combination. The table below lists mainstream standardized models, covering micro pilot, small, medium and medium-large production scales, with real verified operational data for global mine investors’ reference.
|
Daily Processing Capacity
|
Core Crushing Milling Flotation Configuration
|
Final Li₂O Concentrate Grade
|
Comprehensive Lithium Recovery
|
Applicable Project Scenarios
|
|
30TPD Micro Pilot Plant
|
Mini jaw crusher, small ball mill, lab flotation cell group, portable dosing system
|
4.0%–4.4%
|
78%–81%
|
Ore testing, project feasibility verification
|
|
100TPD Compact Full Line
|
Integrated crushing unit, energy-saving ball mill, small desliming system, dedicated lepidolite flotation bank
|
4.3%–4.7%
|
82%–85%
|
Remote small lepidolite mines, low-budget projects
|
|
300TPD Standard Commercial Line
|
Closed-circuit crushing & milling system, multi-stage desliming device, automatic flotation circuit
|
4.6%–5.0%
|
85%–88%
|
Medium-scale lithium mica mines, regional concentrate supply projects
|
|
500TPD Large Full Production Line
|
Intelligent linked crushing milling unit, high-precision desliming system, full-automatic flotation & dehydration equipment
|
4.8%–5.2% High-purity Grade
|
88%–91%
|
Large pegmatite lepidolite deposits, commercial export bases
|
Technical Advantages of Integrated Crushing Milling Flotation Design
The 30–500TPD full lepidolite plant integrates optimized crushing, milling and flotation technologies, solving the mismatch problem of separate equipment configuration in traditional lepidolite processing lines, with prominent advantages in beneficiation stability, cost control and resource utilization.
Graded Crushing & Milling Improve Ore Liberation
The two-stage closed-circuit crushing system controls raw ore particle size uniformly, avoiding excessive coarse particles and excessive fine powder. The matched closed-circuit ball mill and hydrocyclone grading system precisely controls grinding fineness, fully dissociating monomer lithium mica from gangue minerals. Uniform pulp particle size creates stable flotation conditions, laying a foundation for high-efficiency lithium separation.
Targeted Desliming & Acidic Flotation for Lepidolite
Aiming at the high slime characteristic of lepidolite ore, the full plant removes harmful fine clay slime after milling, eliminating reagent waste and lithium particle wrapping. The exclusive acidic flotation system adopts cationic collector formula suitable for lithium mica, achieving high-selectivity separation between lepidolite and quartz-feldspar gangue. The finished concentrate features stable grade and low impurity content, meeting lithium chemical refining standards.
Flexible Scalable Capacity for Phased Production
The modular integrated design supports free capacity adjustment between 30TPD and 500TPD. Mine owners can start with micro-capacity trial production to reduce initial investment risk, and gradually expand crushing, milling and flotation units according to ore reserve growth and market demand. The reserved expansion interface avoids overall equipment reconstruction, realizing phased low-risk project investment.
Low Energy Consumption & Cost-Effective Operation
All crushing and milling equipment adopts energy-saving frequency conversion design, reducing invalid power consumption during ore processing. The automatic quantitative flotation dosing system avoids manual dosing errors and chemical waste. The integrated compact layout reduces site construction investment and daily labor input, with comprehensive operational cost significantly lower than traditional split-type lepidolite processing lines.
Eco-Friendly Closed-Loop Green Production
The full lepidolite plant is equipped with complete process water circulation and tailings dry stacking systems. The water recycling rate reaches over 85%, effectively saving freshwater resources. Zero-discharge tailings disposal mode complies with local environmental protection policies in Africa, Southeast Asia and other major lithium mining areas, helping projects pass environmental audits smoothly.
Full Turnkey Solutions for Lepidolite Processing Projects
We provide one-stop EPC turnkey services covering the whole lifecycle of 30–500TPD full lepidolite crushing milling flotation line projects, helping global small and medium mine investors quickly launch stable and profitable production.
Free Ore Testing & Customized Process Design
Free lepidolite ore beneficiation tests are provided for all clients, including crushing granularity analysis, grinding fineness optimization and flotation reagent ratio testing. Professional engineers formulate exclusive process schemes, plant layout and investment budget according to actual ore conditions, ensuring targeted and efficient beneficiation solutions.
Factory Pre-Testing & Integrated Delivery
All crushing, milling and flotation equipment completes linkage trial operation in the factory before delivery to eliminate hidden faults. Modular equipment is packaged in standard containers for convenient cross-border transportation and rapid on-site assembly, greatly shortening project construction and commissioning cycles.
Overseas On-Site Installation & Commissioning
Professional overseas engineering teams complete full equipment assembly, pipeline docking and system debugging on-site. We dynamically adjust crushing parameters, milling fineness and flotation formulas according to on-site ore changes to ensure stable output of qualified lepidolite concentrate.
On-Site Training & Long-Term After-Sales Support
We provide professional operation and maintenance training for local operators, covering equipment daily operation, parameter adjustment, fault troubleshooting and routine maintenance. 24-hour online remote technical support and global spare parts supply ensure long-term stable operation of the full lepidolite plant.
Market Prospect of Small & Medium-Scale Lepidolite Processing Lines
With the continuous consumption of high-grade spodumene resources, low and medium-grade lepidolite lithium mica ore has become an important supplementary raw material for the global lithium battery industry. Most lepidolite deposits are suitable for small and medium-scale decentralized mining, making 30–500TPD modular full processing lines the most cost-effective investment choice.
The integrated crushing milling flotation full plant balances low investment, flexible production and high beneficiation efficiency, perfectly matching the operational characteristics of small and medium lithium mica mines. It helps mining enterprises maximize low-grade ore resource utilization, reduce comprehensive production costs and obtain stable long-term economic benefits.
Frequently Asked Questions
Why choose integrated crushing milling flotation line for lepidolite processing?
Split equipment configuration easily causes process mismatch and low recovery. The integrated full line realizes coordinated operation of crushing, milling and flotation, with matched particle size, grinding fineness and flotation parameters, ensuring higher and more stable lithium recovery.
Can the 30–500TPD line process low-grade mixed lepidolite ore?
Yes. The adjustable crushing and milling system cooperates with customized acidic flotation formula, which can effectively process low-grade lepidolite ore with high mud content and complex impurities, improving resource utilization rate significantly.
Is the modular plant suitable for remote mining areas?
Absolutely. The compact layout requires less construction land, supports unstable power supply operation, and features simple operation and low labor demand, very suitable for remote small and medium lepidolite mining projects in Africa and Southeast Asia.
How to expand the production capacity of the existing lepidolite plant?
The modular design supports phased capacity expansion. Clients can add crushing units, milling equipment or flotation cell banks on the original foundation without overall reconstruction, realizing low-cost capacity upgrade from 30TPD to 500TPD.
