Turnkey Lepidolite Plant Lithium Mica Flotation Complete Equipment
Release time：
2026-07-08
Source：
GoFine
Lepidolite, commonly known as lithium mica, is a dominant low-to-medium grade hard rock lithium mineral widely distributed in pegmatite deposits across Southeast Asia, Africa and South America. Unlike dense and hard spodumene ore, natural lepidolite features soft texture, fine disseminated particles, high clay slime content and symbiosis with quartz, feldspar and miscellaneous mica minerals. These unique characteristics make lithium mica beneficiation far more difficult than conventional lithium ore processing, easily leading to low lithium recovery and impure concentrate if using standard spodumene flotation equipment.
A professional turnkey lepidolite plant equipped with full set lithium mica flotation complete equipment is specially engineered for refractory lithium mica ore. It adopts targeted desliming pretreatment and customized acidic flotation technology to solve the core pain points of fine particle loss and impurity overrun. This all-in-one turnkey solution covers crushing, grinding, desliming, flotation purification, concentration and dehydration, delivering stable qualified lepidolite concentrate for lithium chemical refining.
Unique Flotation Mechanism for Lepidolite Lithium Mica Ore
Lepidolite lithium mica has completely different surface chemical properties from spodumene, requiring exclusive flotation parameters and reagent systems. Most universal lithium flotation lines fail to achieve ideal separation results due to mismatched pH environment and reagent formulas.
Lepidolite flotation mainly adopts acidic cationic flotation technology. In a low-pH pulp environment, lithium mica surfaces stably adsorb cationic collectors, forming hydrophobic films to attach to air bubbles and float upward for collection. Gangue minerals such as feldspar and quartz are effectively suppressed and remain in pulp tailings. Fine slime pre-removal is the most critical pretreatment step, as excessive clay slime will consume flotation reagents and wrap lithium mica particles, severely reducing flotation efficiency and lithium recovery rate.
The complete turnkey lepidolite plant precisely controls pulp acidity, stirring intensity and bubble stability, realizing efficient separation of fine-grained lithium mica and gangue minerals, which is the core guarantee of high-quality lepidolite concentrate output.
Full Processing Flow of Turnkey Lepidolite Flotation Plant
The integrated lithium mica flotation plant adopts a mature closed-loop low-loss workflow tailored for fine-grained lepidolite ore. Every processing link and equipment matching is optimized for lithium mica’s physical and chemical characteristics, avoiding fine mineral loss and reagent waste.
Raw ore uniform feeding → two-stage closed-circuit crushing → fine closed-circuit grinding → hydrocyclone multi-stage deep desliming → pulp acidic conditioning → targeted reagent dosing → primary roughing flotation → secondary scavenging flotation → multi-stage cleaning flotation → concentrate purification → thickener concentration → full-automatic filter press dehydration → finished lepidolite concentrate stacking → tailings dry discharge
Different from spodumene processing lines, this lepidolite plant adds graded desliming and fine particle recovery modules throughout the flow, specially solving the technical difficulty of ultra-fine lithium mica loss, greatly improving the comprehensive utilization rate of low-grade lithium mica ore resources.
Complete Equipment Configuration & Performance Parameter Table
The turnkey lepidolite plant supports multi-capacity customized configuration. The table below lists mainstream complete equipment sets and verified operational indicators, covering small pilot projects, medium commercial mines and large-scale lithium mica processing bases, providing accurate reference for global mine investment.
|
Daily Processing Capacity
|
Full Flotation Equipment Configuration
|
Finished Li₂O Concentrate Grade
|
Comprehensive Lithium Recovery
|
Applicable Mining Scenarios
|
|
100TPD Mini Lepidolite Plant
|
Mini crusher set, energy-saving ball mill, small desliming cyclone, lab-grade flotation cell group, portable dosing machine
|
4.2%–4.6%
|
80%–83%
|
Mine test projects, small trial production
|
|
300TPD Standard Plant
|
Standard crushing & grinding unit, multi-stage desliming system, dedicated lithium mica flotation bank, automatic reagent station
|
4.5%–4.9%
|
84%–87%
|
Medium small-scale lithium mica mines, regional processing projects
|
|
600TPD Large Commercial Plant
|
Intelligent linked crushing-grinding system, high-precision desliming unit, full-automatic flotation circuit, closed water circulation equipment
|
4.8%–5.2% High-purity Grade
|
88%–91%
|
Large pegmatite lithium mica deposits, concentrate export bases
|
Core Advantages of Specialized Lepidolite Flotation Complete Equipment
Compared with ordinary universal lithium flotation equipment, the dedicated turnkey lepidolite lithium mica flotation equipment has targeted technical upgrades for fine-grained and high-slime lithium mica ore, with prominent advantages in recovery efficiency, product quality and operational cost.
Professional Desliming System Solves Fine Particle Loss
Lepidolite ore contains a large amount of fine clay slime, which is the main cause of low flotation efficiency. The complete flotation equipment is equipped with multi-stage gradient desliming devices, which thoroughly removes harmful slime before flotation. It avoids reagent adsorption waste and lithium particle wrapping, effectively recovering ultra-fine lithium mica minerals that are easily lost in traditional processing lines, increasing comprehensive recovery by 7%–12%.
Customized Acidic Flotation System for Lithium Mica
Different from alkaline spodumene flotation, this turnkey plant adopts exclusive acidic flotation formula and anti-corrosion flotation cells. The system stably controls pulp pH value and cationic collector dosage, achieving high-selectivity separation between lithium mica and gangue minerals. The finished concentrate has low impurity content and stable grade, fully meeting the requirements of lithium salt chemical processing.
Full Automatic Operation & Low Labor Cost
The complete lepidolite flotation equipment integrates PLC centralized control system, realizing automatic feeding, grinding, reagent dosing, flotation parameter adjustment and dehydration. It supports real-time data monitoring and remote fault alarm, requiring only a small number of on-site operators. The automated design greatly reduces manual operation errors and long-term labor costs for mine operation.
Energy-Saving Structure & Low Operational Consumption
All core equipment adopts energy-saving frequency conversion design. The optimized flotation cell impeller structure improves bubble utilization rate and reduces power consumption. The automatic quantitative reagent dosing system avoids manual dosing deviation and reagent waste, cutting daily chemical consumption by 20%–25%. The overall operational cost per ton of ore is significantly lower than traditional semi-automatic lepidolite processing lines.
Eco-Friendly Closed-Loop Production
The turnkey plant is equipped with complete process water circulation and tailings dry stacking systems. The water recycling rate reaches over 86%, minimizing freshwater consumption. The pollution-free tailings disposal mode complies with local environmental protection policies in major lithium mining areas, helping investors pass environmental audits smoothly and realize green and sustainable mine production.
Full Lifecycle Turnkey Project Services
We provide one-stop EPC turnkey services for turnkey lepidolite plant lithium mica flotation complete equipment, covering pre-project evaluation, equipment manufacturing, on-site commissioning and after-sales maintenance, helping global investors quickly launch profitable production.
Free Ore Testing & Customized Scheme Design
Professional laboratory lepidolite flotation tests are provided for free. Engineers analyze ore particle size, impurity composition and lithium grade, formulate exclusive desliming and flotation process parameters, and design targeted plant layout, equipment matching scheme and detailed investment budget to ensure optimal beneficiation indicators for different ore conditions.
Factory Pre-Assembly & Linked Debugging
All complete flotation equipment undergoes full linkage trial operation in the factory before delivery. We eliminate hidden faults such as unstable stirring, pipeline blockage and parameter mismatch in advance, ensuring zero equipment docking problems after on-site installation and shortening project commissioning cycle greatly.
Overseas On-Site Installation & Parameter Optimization
Professional overseas engineering teams complete full equipment assembly, circuit wiring and system debugging on-site. According to actual ore changes on site, we dynamically adjust flotation acidity, reagent ratio and grinding fineness to ensure the plant stably reaches designed concentrate grade and lithium recovery rate.
Professional Training & Global After-Sales Support
We provide targeted training for local operators, covering flotation equipment operation, daily maintenance, parameter adjustment and common fault troubleshooting. Multilingual operation manuals and 24-hour online remote technical support are available all year round, with global spare parts supply to guarantee long-term stable operation of the lepidolite flotation plant.
Industry Application Value & Market Prospect
With the gradual depletion of high-grade spodumene resources, low and medium-grade lepidolite lithium mica ore has become a crucial sustainable source of global lithium raw materials. However, most traditional lithium processing equipment cannot adapt to the fine-grained and high-slime characteristics of lithium mica ore, resulting in low resource utilization rate and poor project economic benefits.
The turnkey lepidolite plant equipped with full set lithium mica flotation complete equipment solves the industry pain point of difficult lepidolite beneficiation. With high recovery, stable quality and low operational cost advantages, it has become the mainstream choice for new construction and upgrading of lithium mica mines worldwide, providing reliable raw material guarantee for the sustainable development of the global lithium battery new energy industry.
Frequently Asked Questions
What is the difference between lepidolite flotation equipment and spodumene flotation equipment?
Lepidolite flotation adopts acidic environment and cationic reagents, equipped with professional multi-stage desliming modules, while spodumene uses alkaline flotation. The dedicated lepidolite equipment is more targeted at fine-grained high-slime lithium mica ore with higher recovery rate.
Can this plant process mixed lepidolite and feldspar ore?
Yes. The customized flotation system can effectively separate lithium mica from feldspar, quartz and mica gangue through precise pH control and reagent matching, realizing efficient purification of mixed lithium mica ore.
What is the qualified standard of finished lepidolite concentrate?
The stably output concentrate Li₂O grade reaches 4.5%–5.2%, which meets the raw material procurement standards of mainstream lithium carbonate and lithium hydroxide manufacturers, suitable for commercial battery-grade lithium raw material refining.
Is the turnkey plant suitable for small-scale remote lithium mica mines?
Absolutely. The modular and compact design adapts to limited site conditions and unstable power supply in remote mining areas, with low investment threshold and simple operation, very suitable for small and medium-sized lithium mica mining projects.
